2000 Loss on Heat Thin Film Oven for Oil Fuel and Petroleum Testing Instruments

The Asphalt Oven determines the effects of heating on asphaltic materials under prescribed conditions. Test results are reported in terms of changes in sample mass and selected properties such as viscosity, penetration, and ductility, based on measurements taken before and after the oven cycle. The dual-purpose oven is designed for loss-on-heating and thin-film tests on bitumen and asphaltic materials. It features a stainless steel interior chamber, a powder-coated steel exterior, and a double-glazed door window for viewing the test chamber. Side-mounted controls include a microprocessor-based digital temperature controller, an independent over-temperature thermostat, a main switch, and indicator lamps. Two rotating platforms are supplied to perform both tests. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for asphalt and bitumen testing applications.

Temperature Range:

• Ambient to 180°C (356°F)

Preset Temperature:

• 163°C ± 1°C

Construction:

• Stainless steel interior chamber
• Powder-coated steel exterior
• Double-glazed viewing window in the door
• Two rotating platforms for loss-on-heating and thin-film tests

Controls and Safety:

• Microprocessor-based digital temperature control
• Independent over-temperature thermostat
• Main switch and indicator lamps

Internal Chamber Dimensions (H × W × D):

• 38 × 52 × 46 cm

External Dimensions (H × W × D):

• 57 × 87 × 63 cm
• Dimensions exclude the motor and handle

Net Weight:

• 151 lbs (68.5 kg)
