4-Position Hotplate Stirrer ALB485

4-Position Hotplate Stirrer is a white ceramic top laboratory hotplate stirrer designed for simultaneous heating and stirring of four samples. It features a stirring range of 0 rpm to 2000 rpm and a PID-controlled heating system with a maximum temperature of 400 °C for uniform heat distribution. The unit offers digital temperature control with inner and outer thermocouples for accurate monitoring and control of both the hotplate and liquid temperatures. The white ceramic top provides excellent heat resistance and durability. Suitable for stirring volumes ranging from 50 ml to 1 L per position. Laboratory Equipment from Atico Exports.

• Heating laboratory containers and samples
• Suitable for distillation processes requiring high temperatures
• Research laboratories
• Healthcare laboratories
• Educational laboratories
• Industrial laboratories
• Quality control laboratories
• Simultaneous heating and stirring of four samples

Stirring Capacity :

• 50 ml to 1 L

Top Ceramic Dimension :

• 140 mm × 140 mm

Power :

• 260 W

Temperature :

• 400 °C

Stirring Range :

• 0 rpm to 2000 rpm

Stirring Speed Accuracy :

• ± 1 rpm

Temperature Accuracy :

• ± 1 °C

Voltage :

• 160 V to 240 V

Motor Power :

• 8 W (DC 14 V)

Weight :

• 14 kg

Included Items :

• Removable Holders – 4
• Clamps with Screws – 4
• Inner Thermocouples (4-pin) – 4
• Outer Thermocouples (4-pin) – 4
• 4-Prong Stainless Steel Clamps (Opens up to 3½") – 4
• Stir Bars – 4

• Four independent stirring positions
• Stirring range from 0 rpm to 2000 rpm
• PID-controlled temperature
• Digital temperature control
• Inner and outer thermocouple temperature monitoring
• Electronic speed control for constant speed during load variations
• Continuous working operation
• White ceramic top for efficient heat transfer
• Square and round plate options available
• Individual or multiple unit operation modes for flexible control
