Abel Closed Cup Flash Point Tester for Oil Fuel and Petroleum Testing Instruments

The Abel Closed Cup Flash Point Tester is designed to determine the closed-cup flash point of petroleum products and other liquids with flash points within the specified range of below −30°C to 70°C inclusive. It is primarily used to assess flammable and combustible materials for shipping, handling, and safety compliance.

The apparatus consists of a brass test cup, test flame applicator, thermometer support, heating plate, and electric heater. The flame applicator is precisely aligned according to the applicable test specifications and pivots to apply the test flame at specified temperature intervals. A hinged thermometer support facilitates convenient placement and removal of the test cup.

The instrument features a 400 W nickel-chromium heater with stepless variable heat control, allowing accurate adjustment and repeatable setting of the temperature rise rate. A built-in needle valve and comparison bead help maintain the required test flame size.

Manufactured by Atico Export for reliable closed-cup flash point determination in petroleum testing, chemical, and safety laboratories.

• Closed-cup flash point determination of petroleum products
• Testing of flammable and combustible liquids
• Assessment of liquid safety for storage and transportation
• Quality control of fuels, solvents, and other liquid products
• Laboratory testing for applicable shipping and safety requirements

Test Method :

• Abel closed-cup flash point determination

Flash Point Range :

• Below −30°C to 70°C inclusive

Test Cup Material :

• Brass

Heating Element :

• Nickel-chromium heater

Heater Power :

• 400 W

Heat Control :

• Stepless variable control

Flame Application :

• Pivoting test flame applicator
• Built-in needle valve and comparison bead

Dimensions (W × D × H) :

• 10 × 17.5 × 11.5 inches (25.4 × 44.5 × 29.2 cm)

Net Weight :

• 25 lb (11.34 kg)
