Abrasion Bohme Tester

The apparatus is basically composed of cast iron horizontal disc with a speed of 30 ° 1 rpm and a diameter of 750 mm, furnished of a 200 mm test track to position a specimen.

Standards Compliance :

• Complied as per EN 1338, 1339, 1340, EN 13892-3, EN 14157

Application :

• The instrument measures a volume loss in a specimen under abrasion test and it–s used in tests such as: paving stones, concrete slabs, slabs made of natural rocks, natural stone slabs.

Control System :

• Control panel with digital revolutions counter with automatic stop after 22 rotations.

Ordering Information :

• Abrasive sand must be ordered separately.

Dimensions (cm) :

• 150 ° 100 ° 85

Weight (kg) :

• 275
