Advanced Environmental Hydrology System Deluxe

Unique system with features suitable for studying fluvial geomorphology including rainfall/runoff hydrographs, groundwater abstraction, river feature formation and fluvial mechanics.

Unique system with features suitable for studying fluvial geomorphology including rainfall/runoff hydrographs for catchment areas of varying permeability, groundwater abstraction by wells with and without surface recharge, river feature formation and fluvial mechanics.

• Stilled inlet tank provides developed river-flow conditions
• Novel outlet tank design for water and sediment flow measurement
• Stainless steel sand tank
• Dual jacks provide adjustable tilt
• Adjustable spray nozzle height
• Fine-grade sand for detailed feature development
• Single sand grade for all demonstrations
• Control and measurement of inlet flows
• Computer data logging supplied as standard
• Supplied with fabricated trays and rings: circular open-ended ring (500mm diameter x 60mm), small square ring (300mm x 300mm x 60mm), closed ring with standpipe (500mm diameter x 60mm), large rectangular rings (1000mm x 500mm x 60mm)
• Impermeable and permeable catchment materials included
• Model structures: cylinders, rectangular bridge piers, rounded bridge piers, streamlined bridge piers
