ATENG 11825 — Aerodynamic Tunnel for Flow Visualization
Anodized aluminum frame and panels made of painted steel.
The unit includes wheels to facilitate its mobility.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
Vertical wind tunnel for flow visualization.
- Variable speed fan:
- Maximum flow rate: 325 m³/h.
- Speed in working section: 0 – 5 m/s.
- Working area with transparent window for process visualization:
- Dimensions of the working area: 180 x 100 x 240 mm.
Additional LED illumination for optimal visualization.
Easily removable transparent screen. ATENG 11825 detail
- Flow straightener (comb): 23 strands with 7 mm spacing.
- Smoke generator:
- Power: 900 W.
- Air velocity sensor, range: 0 – 20 m/s.
- We include solids with various three-dimensional geometries, in order to observe different aerodynamic trajectories. These bodies are:
Aerodynamic profile NACA 2412.
Aerodynamic profile NACA 0015.
Cylinder.
Semi-sphere.
Sphere.
Slotted orifice.
Disc.
Circular orifice.
Tip of an airplane wing.
ISA nozzle.
Model of car and sports car with spoiler.
Truck and van model.
- Operation conditions:
Well ventilated laboratory.
- Storage temperature, range: -25 °C – 55 °C.
- Operating temperature, range: 5 °C – 40 °C.
- Maximum humidity: 80 % at temperatures below 31 °C decreasing linearly to 50 % at 40 °C.
- Maximum sound level: 70 dB.
- Control panel:
Metallic box.
Fan switch.
Fan regulator.
Digital display for air velocity.
Main switch.
