Aggregate Crushing Value Apparatus

The Aggregate Crushing Value (ACV) testing instrument set helps to determine the relative measure of resistance of an aggregate to crushing done by gradually applying the compression load. Aggregate crushing value is the numerical index of the strength of the aggregate and generally used in the construction of pavements and roads.

Used to determine the relative measure of resistance of an aggregate to crushing done by gradually applying the compression load.

Usage :

• Suitable for laboratory experiment

Construction :

• Solid-Robust Construction

Base Plate :

• Material : MS, Size : 200–230mm/sqr. x 6mm

Container :

• Material : Mild Steel, Shape : Cylindrical, Size : 150mm (Dia.) +/-0.5mm x 130–140mm (H)

Plunger :

• Size : 148mm (Dia.) +/-0.5mm x 100–115mm (H)

Tamping Rod :

• 16mm (Dia.) x 600mm (L), Both ends rounded.

Metal Measure :

• Size : 115mm (Dia.) +/- 0.5mm x 180mm (H) +/- 0.5mm

Finishing :

• All parts of the Aggregate Crushing Value apparatus are galvanized or powder coated

Standards Compliance :

• IS 2376 (PART-IV) and BS 812:111
