Aggregate Crushing Value Set

Aggregate crushing value provides a relative measure of the resistance of an aggregate to crushing under a gradually applied compressive load.

Standards Compliance :

• Complied as per BS 812:110

Apparatus – For Aggregates Passing 12.7 mm and Retained on 9.52 mm Sieve :

• Consists of °150 mm steel cylinder, plunger, base plate, tamping rod °16 ° 600 mm and measure °115 ° 180 mm deep.
• Used for aggregate passing 12.7 mm and retained by 9.52 mm sieve.

Apparatus – For Aggregates Smaller Than 9.52 mm :

• Consists of °75 mm steel cylinder, plunger, base plate, tamping rod °8 ° 300 mm and measure °57 ° 90 mm deep.
• Used for aggregates smaller than 9.52 mm.

Construction :

All parts are powder coated or galvanized.

Weight (kg) :

• AECE2101/A - 8.5kg
• AECE2101/B - 32kg

Dimensions (mm) :

• AECE2101/A - 120 ° 120 ° 350 mm
• AECE2101/B - 250 ° 250 ° 600 mm
