Air conditioning and ventilation system Deluxe

ET 620 represents a real air conditioning and ventilation system. The system capacity is sufficient to climatise a laboratory room. Unlike small systems that use conventional climate controllers, this experimental system is equipped with a modern building management system for control. Learn about Air conditioning and ventilation system specifications for optimal educational outcomes.. This corresponds to the state of the art for large air-conditioning systems and is advantageous when presenting complex learning content. For example, real components with the comparative processes are converted into formative images. Learn about Air conditioning and ventilation system manufacturers for optimal educational outcomes..

• practice-oriented air conditioning and ventilation system with water chiller
• manual or automatic operation
• control of the experimental plant using a PLC, operated by touch screen
• screen mirroring: possible to mirror the user interface on up to 10 end devices
• main unit: air duct, ventilator, air condition. system
• air conditioning system with air cooler, electric air heater, humidification
• hoses connect air cooler to water chiller
• air duct: hot galvanised sheet with sight window, pressure measurement (record pressure curves)
• air duct with filter, multi-leaf damper, ceiling vent, protective grating, vent. grille, fire protect. flap, inspection flap, sound insulation link, smoke detector
• data acquisition via PLC on internal USB memory, access to stored measured values via WLAN/LAN with integrated router/LAN connection to customer’s own network or direct LAN connection without customer network
