Air conditioning model

ET 915. 07 is part of the HSI training system for refrigeration and air conditioning technology. In combination with the base unit the operational model of a full air conditioning system is created. Learn about Air conditioning model for educational labs for optimal educational outcomes.. The model is plugged onto the base unit, secured using fasteners and connected with refrigerant hoses to become a complete refrigeration circuit for the air cooler.

• model of an air conditioning system to plug onto the base unit
• training system with HSI technology
• air duct with transparent front and adjustable ventilation flap for recirculating or outer air operation
• evaporator as air cooler
• 2 heaters as air preheater and reheater
• air humidifier with float switch, fan, filling level indication
• thermostatic expansion valve as expansion element
• sensor to record temperature and combined sensor for humidity and temperature
• operation of individual components and of the system and fault simulation via software
• software with control functions and data acquisition via USB under Windows 11
• software: educational software, data acquisition, system operation
