AntiMatter Matters upper level physics experiments

This positron annihilation and gamma-ray coincidence experiment system is designed to demonstrate the fundamental principles of antimatter, positron annihilation, and gamma-ray detection. It enables students to investigate time-coincidence techniques, study the production and annihilation of positrons, perform gamma-ray energy measurements, and understand the working principles of Positron Emission Tomography (PET). The system provides a complete laboratory platform for experiments in nuclear physics, radiation detection, and medical imaging. A digital oscilloscope is required for operation, while a multichannel analyzer is optional. Manufactured by Atico Export India.

Experiments :

• Study Positron Annihilation and Gamma-Ray Coincidence Detection.
• Detect and Analyze 511 keV Gamma-Ray Pairs Produced During Positron Annihilation.
• Measure Gamma-Ray Energy Using CsI(Tl)/SiPM Detectors.
• Demonstrate Time-Coincidence Techniques for Event Detection.
• Locate Hidden Positron Sources Using Coincidence-Based Imaging Principles.
• Study the Inverse Square Law of Gamma Radiation.
• Measure Gamma-Ray Absorption and Verify the Exponential Attenuation Law.
• Investigate Gamma-Gamma Coincidence Using a Cobalt-60 Source.
• Study the Compton Scattering Effect Using a Cesium-137 Source.
• Demonstrate the Basic Principles of Positron Emission Tomography (PET).

Description :

• This positron annihilation and gamma-ray coincidence experiment system is designed to demonstrate the fundamental principles of antimatter, positron annihilation, and gamma-ray detection. It enables students to investigate time-coincidence techniques, study the production and annihilation of positrons, perform gamma-ray energy measurements, and understand the working principles of Positron Emission Tomography (PET). The system provides a complete laboratory platform for experiments in nuclear physics, radiation detection, and medical imaging. A digital oscilloscope is required for operation, while a multichannel analyzer is optional.

Features :

• Table-top experiment using license-exempt radioactive sources.
• Complete control of gamma-ray detection and event processing.
• Demonstration of time-coincidence detection techniques.
• Gamma-ray detection using CsI(Tl)/SiPM detectors.
• Source localization based on positron annihilation gamma-ray pairs.
• Complete electronic controller requiring only a digital oscilloscope.
• Modular experimental platform for multiple nuclear physics experiments.
• Supports additional experiments including Compton scattering, gamma-gamma correlation, and positron production.

Experiments :

• Study Positron Annihilation and Gamma-Ray Coincidence Detection.
• Detect and Analyze 511 keV Gamma-Ray Pairs Produced During Positron Annihilation.
• Measure Gamma-Ray Energy Using CsI(Tl)/SiPM Detectors.
• Demonstrate Time-Coincidence Techniques for Event Detection.
• Locate Hidden Positron Sources Using Coincidence-Based Imaging Principles.
• Study the Inverse Square Law of Gamma Radiation.
• Measure Gamma-Ray Absorption and Verify the Exponential Attenuation Law.
• Investigate Gamma-Gamma Coincidence Using a Cobalt-60 Source.
• Study the Compton Scattering Effect Using a Cesium-137 Source.
• Demonstrate the Basic Principles of Positron Emission Tomography (PET).

Standard Accessories :

• Experimental Platform – Table-top arena (64 × 48 cm) – 1
• Electronic Controller – Integrated detector power supply, pulse processing, and three-channel coincidence counter – 1
• Gamma-Ray Sources – Sodium-22, Cesium-137, and Cobalt-60 sealed sources – 3
• Gamma-Ray Detectors – CsI(Tl) scintillation detector with SiPM, 14 × 14 × 25 mm³ – 2
• Magnetic Bases and Mounting Posts – For detectors and accessories – 1 Set
• Source Holders – For radioactive sources – 1 Set
• Attenuator and Target Holders – Standard – 1 Set
• Circular Source Stage with Cover – For concealed source localization experiments – 1
• Lead-Collimated Source Holder – Lead-lined collimator with shielding accessories – 1 Set
• Lead Shielding Blocks and Wedges – Standard – 1 Set
• Protractor and Radial Positioning Links – For angular measurements – 1 Set
• Connection Cables, Power Cords, and Adapters – Standard – 1 Set

External Equipment Required :

• Digital Oscilloscope (Required)
• Multichannel Analyzer (Optional)
