Apparatus for Determining Curie Temperature of Ferrite Materials

This Curie temperature experiment system is designed to study the magnetic properties of ferrite materials and the transition between ferromagnetic and paramagnetic states. It enables students to determine the Curie temperature of different ferrite samples using the AC electrical bridge method and understand the relationship between temperature and magnetic properties. Manufactured by Atico Export India.

Experiments :

• Study the Transition Between Ferromagnetism and Paramagnetism in Ferrite Materials.
• Determine the Curie Temperature of Ferrite Materials Using the AC Electrical Bridge Method.

Signal Source :

• Sine wave
• Frequency: 1000 Hz
• Output Voltage: 0–2 V
• Continuously adjustable

AC Voltmeter (Range 1) :

• Measurement Range: 0–1.999 V
• Resolution: 0.001 V

AC Voltmeter (Range 2) :

• Measurement Range: 0–199.9 mV
• Resolution: 0.1 mV

AC Voltmeter (Range 3) :

• Measurement Range: 0–19.99 mV
• Resolution: 0.01 mV

Temperature Control :

• Temperature Range: Room temperature to 80 °C
• Resolution: 0.1 °C

Ferromagnetic Samples :

• 2 sets with different Curie temperatures
• 3 samples per set
