Apparatus of A-Scan Ultrasound and Applications

This ultrasonic testing experiment system is designed to demonstrate the principles and applications of ultrasonic pulse-echo measurement. It enables students to measure the velocity of sound in liquids, determine the thickness of solid and liquid samples, evaluate measurement resolution, and detect internal defects in test specimens. The system provides practical training in non-destructive testing (NDT) and ultrasonic inspection techniques. Physics Lab Experiments from Atico Exports.

Experiments :

• Measure the Velocity of Sound in Water or Determine the Thickness of a Water Layer.
• Simulate the Measurement of the Thickness of a Human Organ.
• Determine the Resolution of the Ultrasonic Testing System.
• Measure the Thickness of Solid Objects and Detect Internal Defects in Test Samples.

Pulse Voltage :

• 450 V

Output Pulse Width :

• <5 μs

Detection Blind Area :

• <0.5 cm

Detection Depth :

• Standard

Ultrasonic Transducer Probe :

• Integrated transmitter/receiver
• Frequency: 2.5 MHz

Cylindrical Samples :

• Aluminum alloy
• Crown glass
• Plastic

Resolution Test Block :

• Included

Defect Detection Sample :

• Included
