Apparatus of Forced Vibration and Resonance for Mechanics Physics Lab

This Apparatus of Forced Vibration and Resonance for Mechanics Physics Lab is designed for studying the principles of forced vibrations, resonance phenomena, and frequency response characteristics in dynamic systems. The apparatus utilizes a tuning fork vibration system driven by electromagnetic excitation coils, while an integrated sensing system accurately monitors vibration amplitude. It enables users to investigate the relationship between driving frequency and vibration amplitude, analyze resonance behavior, and study the effects of mass loading and damping on oscillatory systems. The system provides a practical platform for understanding resonance applications in engineering, vibration analysis, and measurement technology.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Study the Relationship Between Vibration Amplitude and Driving Frequency
• Determine the Resonance Frequency of the Tuning Fork System
• Analyze the Sharpness of Resonance (Q Factor)
• Investigate the Effect of Attached Mass on Vibration Frequency
• Establish the Relationship Between Resonance Frequency and Added Mass
• Measure Unknown Masses Using Resonance Frequency Techniques
• Examine the Influence of Damping on Resonance Characteristics
• Compare System Behavior Under Different Structural and Damping Conditions

Educational Objectives

• Understand the Principles of Forced Vibration and Resonance
• Analyze Amplitude-Frequency Characteristics of Vibrating Systems
• Study the Effect of Mass Loading on Resonance Frequency
• Investigate the Significance of the Q Factor in Resonance Systems
• Learn Practical Methods for Vibration Measurement and Frequency Analysis
• Explore the Influence of Damping on Dynamic System Performance

Tuning Fork and Support :

• Dual-Arm Tuning Fork
• Natural Frequency: Approximately 248–256 Hz (Without Loading)

Signal Generator :

• Adjustable Frequency Range: 200–300 Hz

Frequency Control and Display :

• Range: 200–300 Hz
• Resolution: 0.01 Hz

AC Voltmeter :

• Range: 0–2000 mV
• Resolution: 1 mV

Stainless Steel Damping Sheets :

• Dimensions: 50 × 40 × 0.5 mm
• Quantity: 2 Pieces

Mass Blocks :

• 6 Pairs of Different Masses

Tuning Fork Drive System :

• Electromagnetic Excitation and Sensing Coils

Standard Supply

• Main Electric Unit × 1
• Mechanical Stage × 1
• Mass Block Sets × 6 Pairs
• Stainless Steel Damping Plates × 2
• Magnetic Steel Pieces × 2
• BNC Cables × 4
• Allen Wrench × 1
• Power Cord × 1
• Instruction Manual × 1

• Clear and Observable Physical Phenomena
• Stable and Reliable Experimental Results
• Comprehensive Experimental Capabilities
• Easy Operation with High Measurement Accuracy
