Asphalt Binder Analyzer

The ABA Asphalt Binder Analyzer is used to determine the binder content of hot mix asphaltic bituminous mixtures by the method of loss on ignition. The system combines a sophisticated furnace and weighing system to continuously measure the weight loss of a bituminous mixture during combustion and automatically calculates its binder content at the end of the test.

Oven and Afterburner

Features

• High efficiency heating system with afterburner chamber for a total combustion of exhaust fumes to minimize emissions and conform with EU Directives
• Sample size up to 4500 g for more representative test results
• Maximum power rating is 7,5 kW

Hardware

Features

• 16 bit microprocessor with one CPU card controlling test data display, temperature, database and internal functions
• USB support to store test results
• On board thermal printer
• Weighing system 15000 g capacity, 0,1 g resolution and detecting mass variations of 0,1 g
• PID closed loop thermoregulation for both oven and afterburner chamber
• 950 °C Afterburner 540 C oven set temperature according to standard
• Touchscreen with 800x480 resolution and 65000 colors

Firmware

Features

• Bidirectional real time communication with the weighing system
• Test setting menu with physical and descriptive sample parameters (initial weight, weight loss percentage, correction factor)
• Calibration menu to check and set the temperature and weight calibration for possible manual control of the test performance
• Test performance menu with simultaneous display of all the test data
• Internal memory for up to 100 tests

Safety Features

Features

• Automatic door locking after 150 C
• Automatic monitoring of closed door before test start

STANDARDS COMPLIANCE :

• COMPLIED AS PER TS EN 12697-39, AASHTO TP53, AASHTO T308, ASTM D6307

Supply / Components :

• Supplied complete with 2 specimen baskets with a safety cover with a carrying tray mounted, a fork to catch the tray, and 3 meter metal exhaust pipe.

Optional Accessories :

• If the tests are to be performed consecutively without waiting for cooling, Spare Basket and Tray Set and Cooling cage should be ordered separately.
• Spare Basket and Tray Set consists of 2 pcs. basket (one has a safety cover) and a carrying tray mounted.

Dimensions (mm) :

• 700x1000x1280

Weight (kg) :

• 135

Power (kW) :

• 7,5

Power Supply :

• 380 V, 50 Hz, 3 ph

Spare Parts & Accessories :

• Spare Basket and Tray Set
• Cooling Cage
• Fork
• Metal Exhaust Pipe, 3 meter
