Assembly exercise: piston compressor

Piston compressors are a type of driven positive displacement machines, which transfer energy from the compressor to the fluid via a variable volume. This device is an air-cooled piston compressor that sucks in ambient air and from this generates compressed air.

• single-stage piston compressor assembly kit, air-cooled, with fan flywheel and intake filter
• part of DigiSkills learning projects
• disassembled piston compressor with small parts kit and 4 assembly devices, delivered in stable storage system with foam inlay
• compressor consisting of crankcase with cylinder, piston and rod, cylinder head and valve plate
• together with base unit: functional test incl. adjustment and alignment procedures
• augmented reality: visualisation of machine elements, display of exploded views, functions
• online access to the Media Center with multimedia instructional materials: PDF, CAD files, STEP files, videos
