Assembly of a Control Pneumatic Valve Unit

The Assembly of a Control Pneumatic Valve Unit, is a globe valve with bellows supplied in a carrying case that also includes a manual with two-dimensional plans, drawing of individual parts and drawing of the whole unit, the main parts list and the regulations related to the manufacturing materials.

ATENG 11920 — Assembly of a Control Pneumatic Valve Unit

Carrying case made of aluminum.

Main metallic elements made of stainless steel.

• Control pneumatic valve with clamp connections:
  DN 25.
  PN 16.
• Stoke: 11 mm.
• Kv: 9.3 m³/h.
  Body and cover made of cast iron.
  Disc, seat, bellows and rod made of stainless steel.
  Seal made of laminated graphite with stainless steel.
  Gland nut made of stainless steel.
• Operation temperature: -20 °C / +250 °C.
• Leak test set:
  Manual pump.
  Manometer.
  Flange connections.
• Assembly and disassembly tools set:
  Tool case with several compartments.
  Box with spare nuts and bolts (screws, nuts, washers and pins).
  Four combination wrenches.
  Adjustable wrench.
  Soft face hammer.
  Cylindrical punch.
  Two spare seals.
