Atmospheric distillation of petroleum products - manual ASTM D1078 , ASTM D850 and ASTM D86 for petroleum, petrochemicals, pharmaceuticals, aerospace, cosmetics, food, etc.

The manual atmospheric distillation apparatus is designed for determining the distillation characteristics of petroleum products under controlled laboratory conditions. It features an electric heating element and a temperature range of 0C to 400C, making it suitable for petroleum testing and laboratory analysis. Manufactured by Atico Export under expert engineering guidance for reliable oil-field and petroleum testing applications.

Heating System :

• Electric heating element

Temperature Range :

• 0C to 400C

Supplied With :

• 100 mL test tube
• 125 mL distillation flask
• 50 mm ceramic plate
• 100 mm ceramic plate
• Bag of pumice stones
• 5 mL test tube

Options and Accessories :

• Cryostat for Group 1 and Group 2 analysis
• Glass cooling bath
• 200 mL distilling flask

Safety Features :

• Compressed air cooling at the end of the test
• Earth leakage circuit breaker

Software :

• Not applicable

Power Supply :

• 230 V, 50 Hz, 6 A

Dimensions :

• Width: 380 mm
• Depth: 490 mm
• Height: 510 mm

Weight :

• 21 kg

Cooling System :

• Compressed air
