Automated Air Release Valve Analyzer for Oil and Petroleum Testing Equipment

The Automatic Air Release Value Apparatus is designed to determine the air release properties of turbine oils, hydraulic oils, and lubricating oils. Air release is an important performance characteristic in applications where agitation causes air bubbles to become entrained in the oil.

During testing, the oil sample is heated to a specified temperature and blown with compressed air at a controlled flow rate. After the airflow is stopped, the apparatus measures the time required for the entrained air volume to decrease to 0.2%.

The system consists of a test vessel and air flow control equipment, along with an integrated touchscreen control panel, circulation bath, balance, and automatic lift system. It provides automated timing and density calculation to support air release value determination.

Manufactured by Atico Export for reliable air release testing and performance evaluation of industrial lubricating oils.

• Determination of air release properties of turbine oils
• Testing of hydraulic oils and lubricating oils
• Evaluation of air bubble separation time
• Quality control of industrial oils

Temperature Range :

• Ambient to 75°C (167°F)

Sample Temperature Stability :

• ±0.1°C

Air Temperature Stability :

• ±0.2°C

Density Accuracy :

• ±0.001 g/mL

Power Supply :

• 115 V, 60 Hz, single phase
• 230 V, 50/60 Hz, single phase

Maximum Power Consumption :

• 1700 W

Dimensions (W × D × H) :

• 24 × 23 × 34 inches (60.96 × 58.42 × 86.36 cm)

Net Weight :

• 53 kg (115 lbs)

Standard Accessories :

• 5 mL sinker
• 10 mL sinker
• Integrated balance
• Integrated circulator
• Air bath for sinker
• Tubing and fittings
• Platinum wire
• Jacketed test vessel

Optional Accessories :

• Drying oven for warming test oil up to 100°C

• Integrated touchscreen control panel
• Automatic lift system for moving the test vessel between the air source and balance sinker
• Automatic calculation of final sample density
• Integrated circulation bath with water-level indicator
• Integrated balance for density measurement
• Secure clamping mechanism for the air tube
• Automated draining of the jacketed test vessel
• Safety shield for enhanced operational safety
• Integrated circulation bath and air bath for the sinker
• Compressed air heater
• Over-temperature and over-pressure protection
• Automatic measurement of air release time
• LIMS compatibility
• Optional drying oven for warming test oil to temperatures up to 100°C
