Automated HTHP Cement Consistometer 25 KSI oil testing instruments by ATICO EXPORT

The automated HTHP cement consistometer was specifically engineered to determine the thickening time of well cements under simulated down-hole pressures and temperatures. The HTHP consistometer offers a computerized data acquisition and control system, automatic temperature and pressure control and a variable speed motor in one easy-to-use unit.

Maximum pressure :

• 25,000 PSI (172.4 MPa)

Maximum temperature :

• 400°F (204°C)

Consistency range :

• 0 - 125 Bc

Digital temperature controller :

• 0.1° resolution

Pressure indicator resolution :

• 1 PSI

High- and low-pressure alarms :

• included

Slurry cup rotational speed :

• Variable up to 150 RPM

Size :

• 22.5” × 27.5” × 70” (57 × 70 × 178 cm)

Weight :

• Approx. 450 lb (204 kg)

Crated size :

• Approx. 26” × 34” × 76” (66 × 86 × 193 cm)

Crated weight :

• Approx. 750 lb (340 kg)

Requirements :

• Air / nitrogen supply (100 - 120 PSI)
• Water supply for cooling (40 PSI)
• Water drain
• 230-Volt, 50 / 60 Hz, 25-Amp electrical power supply

Software Features :

• Reports real-time data that can be exported to Excel, Word or similar files
• Enables programming of temperature, pressure ramps and motor speed
• Operates multiple units with one computer

Components :

• Mineral oil, 1 gallon
• Tool kit
• Rupture disk, 28,000 PSI
• High-pressure filter
• Filter element
• O-ring for filter element
• O-ring for cell cap
• Air filter
• Oil filter
• O-ring for cooling jacket, FFKM
• Wrench, box end, 5/8"
• Hose kit
• Fuse, 10 Amp, 5 mm × 20 mm

Slurry Cup Components :

• Slurry cup assembly without expansion chamber
• Slurry cup assembly with expansion chamber
• Sleeve
• Diaphragm, molded
• Diaphragm, flat
• Paddle pin
• Pivot bearing
• Pivot bearing gasket
• Paddle
• Paddle shaft, 7.75" (for slurry cup without expansion chamber)
• Diaphragm retaining ring
• Drive disk
• Drive bar
• Shear pin
• Drive pin
• Gasket
• Drive disk set screw
• Diaphragm support
• Slurry cup base
• Slurry cup locking ring
• Paddle shaft, 9.125" (for slurry cup without expansion chamber)
• Expansion chamber lid

Potentiometer Components :

• Potentiometer assembly
• Calibration spring
• Body
• Resistor
• Contact spring
• Contact arm
• Contact strip
• Grounding cable retaining screw
• Grounding contact spring

Calibration Components :

• Calibration stand assembly
• Weight hanger
• Weight set

Optional :

• Spare parts kit
• Paddle for dynamic settling test

• Touch-screen display
• Computerized data acquisition and control system provides detailed test information in convenient formats
• Can control multiple units from one computer
• Automatic temperature and pressure control
• Automatic programmable variable speed motor (0 - 150 RPM) powered by a magnetic drive
• Visual indicator provides an at-a-glance status update during testing
• Smaller cell and more efficient cooling system provide quicker cool-down times
• Compact footprint saves valuable laboratory space
