Automatic Cloud and Pour Point Analyzer for Oil and Petroleum Testing Equipment

The Automatic Cloud and Pour Point Analyzer is designed to determine the cloud point and pour point of petroleum products and biodiesel fuels. These properties indicate how fuels, lubricants, and other petroleum products behave at low temperatures.

During testing, the specimen is cooled at a specified rate and examined periodically. The cloud point is recorded as the temperature at which a cloud first appears at the bottom of the test jar. The pour point is determined as the lowest temperature at which movement of the specimen can be detected.

The analyzer uses optical detection for cloud point measurement and an automatic tilt method for pour point determination. It features an integrated cooling system, wireless measuring heads, a touchscreen interface, and automated calibration functions. Test results can be viewed, printed, exported, and transferred to a Laboratory Information Management System (LIMS).

Manufactured by Atico Export for reliable low-temperature testing and quality evaluation of petroleum products and fuels.

• Determination of cloud point in petroleum products and biodiesel fuels
• Determination of pour point in lubricating oils and fuels
• Evaluation of low-temperature flow characteristics
• Testing of fuel suitability for low-temperature operating conditions
• Quality control in petroleum blending and pipeline operations
• Assessment of wax crystal formation and potential filter blockage

Industrial Touchscreen Interface :

• 10.4-inch integrated colour touchscreen
• Multi-level password protection
• Pre-programmed standard test methods
• Option to create user-defined test programs
• Temperature-versus-time graphs for sample and bath temperatures
• Results can be searched, viewed, printed, and exported to LIMS

Calibration Features :

• Three-point electronic calibration
• Ten-point RTD offset calibration
• Sample calibration
• Jacket calibration

Connectivity :

• Four USB interfaces
• Ethernet network connection
• LIMS compatibility

Technical Specifications :

Detection Method :

• Cloud Point: Optical detection
• Pour Point: Automatic tilting method

Cooling System :

• Internal cooling system

Temperature Range :

• −105°C to +50°C (−157°F to +122°F)

Temperature Accuracy :

• ±0.1°C

Tilt Interval :

• 1°C or 3°C, depending on the test method
• User-defined interval from 1°C to 5°C for custom methods

Display :

• 10.4-inch colour touchscreen

Interfaces :

• Four USB ports
• Ethernet

Password Protection :

• Multi-level password capability

Dimensions (W × D × H) :

• 12.5 × 26.25 × 15.5 inches (31.75 × 66.68 × 39.37 cm)

Net Weight :

• 41 kg (90 lbs)

Fully Automatic Operation :

• Automatic cloud point determination by optical detection
• Automatic pour point determination using the tilt method
• Integrated cooling system
• Wireless cloud point measuring head
• Wireless pour point measuring head
• Automated test cycle and result recording
