Automatic Cold Filter Plugging Point Analyzer for Oil Fuel and Petroleum Testing Instruments

The Cold Filter Plugging Point (CFPP) Tester determines the lowest temperature at which diesel, biodiesel, and heating fuels can pass through a standardized wire mesh filtration device under specified cooling and testing conditions. The test identifies the temperature at which a fuel fails to pass through a 45-micron mesh filter within the prescribed time, helping estimate the lowest temperature for trouble-free fuel flow in certain fuel systems. The system provides automated testing in accordance with ASTM D6371 and related international test methods. It features an integrated 12-inch touchscreen panel PC, dedicated operating software, internal vacuum generation, and a direct cooling system that eliminates the need for solvent cooling baths. The software displays and records analytical parameters in real time and monitors system components, including solenoid valves, cooling equipment, pressure sensors, and the PT100 Class A temperature probe. Audible alarms and displayed messages indicate test completion, errors, and malfunctions. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for low-temperature fuel testing applications.

Testing Principle:

• Sample cooled according to a selected temperature profile
• Vacuum pressure: 20 mbar
• Filtration through a 45-micron mesh filter
• Test completion when the sample takes more than 60 seconds to reach the upper barrier detector or more than 60 seconds to return below the detector after release

Cooling System:

• Direct cooling system
• One-stage cooling: Down to -45°C
• Two-stage cooling: Down to -80°C
• Rapid cooling capability
• Integrated CFC-free motor compressors
• Pressure controller for first- and second-stage compressors
• Thermostat for second-stage activation
• Thermo-switch for each cooling and heating jacket
• Internal overload protection for motor compressors

Control and Software:

• Integrated panel PC with 12-inch TFT/LCD touchscreen
• Display resolution: 1024 × 768
• 16.2 million colors
• Real-time display and graphing of analytical parameters
• Microsoft Excel-compatible data files
• Internal vacuum generation system
• Monitoring of solenoid valves, cooling system, pressure sensors, and temperature probe
• Audible alarms and displayed messages for test completion, errors, and malfunctions

Measurement Specifications:

• Resolution: 0.06°C
• Accuracy: ±0.1°C
• Repeatability and reproducibility: According to standard test methods or better
• Data storage capacity: 60,000 analyses

Standard Accessories:

• Calibrated aspiration pipette with CFPP filter kit
• Power cable without plug
• Calibrated test jar
• User manual
• Vacuum system connection tube
• Operating software
• Spacer

Dimensions (W × D × H):

• 26 × 23.75 × 31.5 inches (66 × 60 × 80 cm)

Net Weight:

• 150 lbs (68 kg)
