Automatic Curing Chamber oil and petroleum testing instruments by ATICO EXPORT

The automated curing chamber is used to prepare well cement specimens for compressive strength tests. It is necessary to determine the amount of time required for a cement to develop compressive strength so that drilling and production operations can be resumed as quickly as possible. The goal is to design a slurry that can quickly develop compressive strength so that the “waiting on cement” time may be minimized. The automated curing chamber provides a means of curing cement specimens under typical down-hole temperatures and pressures.

Maximum operating temperature :

• 600°F (315.6°C)

Maximum operating pressure :

• 5000 psi (34.5 MPa)

Single deep accommodates :

• 8 cubes

Double deep accommodates :

• 16 cubes

Requirements :

• Air supply: 100 - 120 psi (689 - 827 kPa)
• Cooling water: 40 psi (276 kPa)
• Electrical power supply: 230 Volt, 50/60 Hz, 30 Amp

Dimensions :

• 26" × 34" × 76" (66 × 86 × 193 cm)

Weight :

• Approximately 750 lb (340 kg)

• Creates 2" cement cubes according to API guidelines
• Touch-screen display controls temperature and pressure
• Custom test profiles can include multiple temperature and pressure ramps
• Cooling system quickly cools the test cell automatically
• Dual compression mold meets ASTM standard C-109
• Optional expansion module uses a linear transducer inside the wall of the cell to measure expansion or shrinkage
