Automatic flash point - Tag ASTM D56 for petroleum, petrochemicals, pharmaceuticals, aerospace, cosmetics, food, etc.

Designed for the automatic determination of flash point in petroleum products using the Tag closed-cup method. The instrument features temperature control, dual flash point detection using a thermocouple and ionization ring, and automatic gas shut-off at the end of testing. Manufactured by Atico Export to support reliable petroleum testing and laboratory analysis.

Technical Specifications :

• Temperature range: 30C to 110C
• Temperature measurement: PT100 probe
• Flash point detection: Thermocouple and ionization ring
• Ignition presentation: Automatic gas or electric
• Automatic gas shut-off at the end of the test
• Result storage: Up to 200 results

Supplied With :

• Test cup
• Cover
• PT100 probe
• Detection cable
• Detection thermocouple
• Insulated tubing set for cryostat connection
• Electric ignitor
• Antifreeze ring

Options and Accessories :

• Cryostat
• Gas cartridge with holder
• Gas cartridge
• Thermal printer
• Printer cable
• Printer paper

Safety Features :

• Automatic gas shut-off at the end of the test

Software and Controls :

• Membrane keyboard
• Multilingual interface in French and English
• Automatic barometric correction or manual atmospheric pressure entry
• Selectable units: C, F, mbar and mmHg
• Memory for the last 100 results

Power Supply :

• 230 V, 50/60 Hz, 4 A

Dimensions :

• Width: 270 mm
• Depth: 550 mm
• Height: 550 mm

Weight :

• 20 kg
