Automatic Houillon Viscometry System for Oil Fuel and Petroleum Testing Instruments

The Fully Automatic Kinematic Viscometer is a compact, bench-top system designed to measure the kinematic viscosity of transparent and opaque Newtonian liquids, including base oils, formulated oils, diesel, biodiesel blends, residual fuel oils, marine fuels, used lubricating oils, petroleum products, and water-based fluids. It uses the Houillon viscometer tube method and offers high throughput, low sample volume, and low solvent consumption. The system features automatic flow-time measurement with precise meniscus detection, self-calibrating optical sensors, automatic cleaning and drying, integrated back-flushing, and accurate temperature control. It includes two temperature-controlled baths with two viscometer tubes per bath, allowing simultaneous measurements at different temperatures. The stand-alone unit operates through a 12-inch capacitive touchscreen without requiring a PC. Optional features include an autosampler, dual-solvent cleaning, duplo measurement capability, and PC software. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum and lubricant viscosity testing applications.

Measuring Range:

• 0.3–3,000 mm²/s (cSt) at 40°C

Temperature Range:

• 20°C to 120°C (68°F to 248°F)
• An external chiller is required for temperatures around ambient

Temperature Stability:

• Better than ±0.02°C

Timer Accuracy:

• 0.001 seconds

Sample Volume:

• 0.3–1.0 mL

Solvent Consumption:

• 2–3 mL per sample cycle

Sample Throughput:

• Up to 80 samples per hour per bath under optimal conditions
• Typical cycle time: 3–10 minutes per viscometer tube

Bath Configuration:

• Number of baths: 2
• Viscometer tubes per bath: 2
• Simultaneous measurements at two temperatures

Viscometer System:

• Houillon-type viscometer tubes
• Optical, self-calibrating sensors
• Automatic flow-time measurement
• Ultraprecise meniscus detection
• Automatic calibration of optical amplifiers
• Optional duplo measurement using a single sample injection

Automatic Cleaning System:

• Integrated cleaning pump
• Automatic solvent injection
• Fully automatic cleaning and drying
• Integrated back-flushing
• Optional single- or dual-solvent injection
• Low solvent consumption
• Fast tube replacement without connecting tubes to optical sensors
• Viscometer tubes can be replaced without draining the bath

Temperature Control and Monitoring:

• Accurate temperature control
• High-resolution 12-inch capacitive touchscreen
• On-screen bath temperature graphs
• Bath backlighting for improved visibility of viscometer tubes and sensors
• Programmable bath scheduler for preset on/off times
• Adjustable warm-up and cleaning parameters

Control and Diagnostics:

• Stand-alone operation without a PC
• Optional PC software for result storage, calculations, and system control
• Diagnostic alerts for empty solvent tanks, full waste bottles, insufficient vacuum, and other operating issues
• Optional modular autosampler for unattended operation

Integrated Calculations:

• Viscosity Index (VI) calculations

Data Export:

• USB storage device

Standard Accessories:

• Viscometer tubes
• Starter kit
• Calibration standards
• Bath oil

Optional Accessories:

• Autosampler
• PC software
• Dual-solvent cleaning system
• Duplo measurement capability
