Automatic Pensky Martens Closed Cup Flash Point Tester for Oil and Petroleum Testing Equipment

The Automatic Pensky-Martens Closed Cup Flash Point Analyzer is designed to determine the flash point of petroleum products and other combustible liquids using the closed-cup test method. It is suitable for biodiesel, distillate fuels, new and used lubricating oils, residual fuel oils, cutback residuals, mixtures of petroleum liquids containing solids, and petroleum liquids that tend to form a surface film during testing.

The analyzer features an integrated processor-based computer system with an 8.4-inch touchscreen interface for test selection, operation, and result display. Flash point detection is performed using a thermocouple and an ionization ring. The automated cover and motor assembly provides three selectable positions: Open, Clean, and Test.

An integrated dual-fan cooling system rapidly cools the test cup and surrounding environment. Automatic barometric pressure correction, temperature calibration functions, data storage, and an inert-gas fire suppression system support reliable and safe laboratory operation.

Manufactured by Atico Export for dependable flash point testing and quality control in petroleum testing laboratories.

• Flash point determination of biodiesel and distillate fuels
• Testing of new and used lubricating oils
• Analysis of residual fuel oils and cutback residuals
• Testing of petroleum liquids containing solids
• Evaluation of petroleum liquids that form surface films during testing
• Quality control and safety evaluation of combustible petroleum products

Detection System :

• Thermocouple and ionization ring

Temperature Range :

• Ambient temperature to 405°C

Heating Rate :

• In accordance with ASTM D93 Procedures A, B, and C

Stirring Rate :

• 0 to 300 ± 5 RPM

Cycle Time :

• Approximately 5 minutes with the rapid fan cooling system

Ignition Test Frequency :

• User-selectable according to the test method

Cooling System :

• Integrated dual-fan system
• First fan directly cools the test cup
• Second fan cools the surrounding environment

Barometric Pressure Correction :

• Automatic

Methods and Data Storage :

• Storage capacity limited by the available computer hard disk space

Temperature Calibration :

• Two-point sample temperature calibration
• Multipoint temperature calibration with more than two points
• Certified Reference Material (CRM) calibration with automatic software correction based on the tested CRM

Communication Interfaces :

• Ethernet
• RS-232
• Two USB ports: one front port and one rear port

Security :

• Three-level password protection

Safety System :

• Fire prevention
• Fire detection
• Inert-gas fire suppression

Dimensions (W × D × H) :

• 10⅞ × 17.5 × 26 inches (27.63 × 44.45 × 66.04 cm)

Net Weight :

• 27.22 kg (60 lbs)

• Automatic closed-cup flash point testing
• Dual flash detection system using a thermocouple and ionization ring
• Electric or gas ignition, selectable through software with manual switching
• Flash point operating range from ambient temperature to 405°C
• Integrated dual-fan cooling system
• 8.4-inch LCD touchscreen interface
• Automatic barometric pressure correction
• Automated three-position cover and motor lift system
• Selectable Open, Clean, and Test positions
• Storage capacity for more than 65,000 test results, subject to available storage
• User-defined test programs and quick-test functionality
• Inert-gas fire suppression system
• Integrated fire prevention and detection systems
• Three-level password protection
• LIMS connectivity for laboratory data management
