Automatic Potentiometric Titrator Basic Model

Description :

The Automatic Potentiometric Titrator is designed for accurate electrochemical and volumetric analysis with a measuring range of -2000.0 mV to 2000.0 mV and temperatures up to 100°C. It features a 250 mL titration cup for high-precision analysis and supports automated cleaning, titration, and pH-volume curve plotting. Compatible with robotic sampling systems, it enables efficient and reliable automated sample processing. Equipped with advanced software control, multiple titration modes, and extensive data storage, it is an ideal solution for modern laboratory applications. Manufactured by Atico Export India.

Applications :

• Acid-base titration
• Redox titration
• Precipitation titration
• Complexometric titration
• Non-aqueous titration
• Pharmaceutical laboratories
• Chemical laboratories
• Research and development laboratories
• Quality control laboratories
• Food and beverage testing
• Environmental analysis

Standard Accessories :

• Power Link Line
• Composite Electrode
• Magnetic Stirrer
• Silicone Plug
• Anti-Diffusion Head
• Glass
• Stirrer

Measuring Range :

• -2000.0 mV to 2000.0 mV, -20.000 pH to 20.000 pH

Temperature Range :

• 0°C to 100°C

Temperature Measurement Accuracy :

• ±0.1°C

Resolution :

• 0.1 mV / 0.001 pH

Precision :

• 0.1 mV / 0.005 pH

Titration Cup Capacity :

• 250 mL

Burette Capacity :

• 1 mL, 5 mL, 10 mL, 25 mL, 50 mL (Standard: 10 mL)

Burette Filling Time :

• 10 Seconds (100% Filling Speed)

Burette Resolution :

• 1/48,000

Measurement Modes :

• MEAS (Measuring pH/mV/T), CAL (Multipoint pH Calibration), SET (Settings and Modes), MET (Iso-Volumetric Titration), DET (Dynamic Titration)

Titration Modes :

• Acid-Base Titration
• Redox Titration
• Precipitation Titration
• Complexometric Titration
• Non-Aqueous Titration

Control Mode :

• PC with Software

Liquid Channel :

• Built-in

Liquid Filling Channels :

• Up to 8 Channels

Stirring Modes :

• Top Screw Agitator or Magnetic Stirring

Pipeline Material :

• PTFE

Automatic Sampler Compatibility :

• Compatible with Robotic Sample Injection System

Data Storage :

• Over 300 GB (More than 10,000 Records)

Interface :

• 1 USB, RS232 Serial Port, Ethernet

Record Methods :

• More than 10,000 Methods

Compliance Standards :

• FDA, GMP, GLP (Audit Tracking, Hierarchical Management, Electronic Signature)

Dimensions :

• 200 × 185 × 320 mm

Weight :

• 5.5 kg

• Complies with FDA, GMP, and GLP standards
• Multiple titration modes for versatile applications
• High-precision electrochemical measurements
• Automated cleaning, titration, and pH-volume curve plotting
• High-resolution burette for accurate dispensing
• Fast sample processing
• Expandable sample capacity
• Multiple liquid channels
• Large onboard data storage
• Easy maintenance
• Compatible with automated robotic sampling systems
• PC software control for efficient operation
