Automatic Reference Fuel Blending System for Fuel Testing Instrument

The Automatic Reference Fuel Blending Unit is designed for the automated preparation of cetane and octane reference fuels, as well as standardization fuels for octane and cetane test engines.

The system prepares reference fuel blends by weight using a high-precision balance and gravimetric measurement. Its automatic calculation and control program ensures accurate blending, with a balance precision of 0.01 g. The operator selects the applicable test method, enters the target octane or cetane number and sample volume, and initiates the blending process. The unit automatically prepares and delivers the fuel blend.

The professional software controls the blending process and automatically saves blend data, including date, time, serial number, test method, blending components, and blend parameters. A free blending function is also available for preparing specialized fuel mixtures for specific engine requirements.

Manufactured by Atico Export for reliable and efficient reference fuel preparation in octane and cetane testing laboratories.

• Automated preparation of octane reference fuels
• Automated preparation of cetane reference fuels
• Standardization of octane and cetane test engines
• Gravimetric fuel blending
• Preparation of customized fuel blends for specialized engines
• Fuel testing and quality control laboratories

Application :

• Cetane and octane reference fuel preparation

Measurement Mode :

• Gravimetric measurement using a precision balance

Fuel Blending Mode :

• Automatic fuel blending controlled by software

Operating Mode :

• Built-in touch-screen control panel

Tank Quantity :

• 6 tanks

Blending Accuracy :

• ±0.01 ON/CN

Blending Speed :

• 2 minutes per 500 mL

Monitoring System :

• Real-time fuel temperature monitoring
• Real-time tank liquid-level monitoring

Calibration Function :

• Precision balance calibration
• Pump calibration

Blend Data Recording :

• Date and time
• Serial number
• Test method
• Blending components
• Blend parameters
• Automatic data saving

Safety System :

• Electrical protection devices

• Six-tank automatic fuel blending system
• High-precision balance for gravimetric measurement
• Balance precision of 0.01 g
• Touch-screen control panel with user-friendly software
• Automatic calculation and control of blending operations
• Reduced manual intervention and blending errors
• Real-time monitoring of fuel temperature and tank liquid levels
• Automatic delivery of prepared fuel blends
• Automatic saving of blending data
• Free blending function for specialized fuel mixtures
• Calibration function for the precision balance and pumps
• Electrical protection devices and temperature monitoring
• Designed for consistent octane and cetane reference fuel preparation
