Automatic Vacuum Distillation System for Oil Fuel and Petroleum Testing Instruments

The Automatic Vacuum Distillation System determines the boiling range of petroleum products that can be partially or completely vaporized at a maximum liquid temperature of 400°C under reduced pressure. The sample is distilled under controlled vacuum conditions designed to provide approximately one theoretical plate of fractionation. Initial and final boiling points are measured, and a distillation curve relating volume percentage distilled to atmospheric equivalent boiling point temperature can be prepared. The system features fully automatic operation, PC-based control, automatic cleaning, and a vacuum step-down function to inhibit foaming. Windows-based software guides the operator through the distillation process, displays equipment status, and presents results in tables and graphs as testing progresses. Data can be saved in standard formats, opened in spreadsheet applications, or exported to LIMS. Files can be accessed through USB drives or an Ethernet connection. A color printer is provided for printing reports. Safety shields and doors protect the operator, while the removable receiver and accessible components simplify maintenance. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum vacuum distillation testing applications.

Distillation Temperature Range:

• Ambient to 400°C (752°F)

Condenser Temperature Range:

• Ambient +5°C to 150°C

Vacuum Range:

• 1.00 mmHg to 50 mmHg (0.13 to 6.7 kPa)

Control and Operating Features:

• Fully automatic operation
• PC-based control system
• Windows-based operating software
• Step-by-step guided distillation process
• Adjustable distillation parameters during testing
• Real-time process diagrams showing equipment status
• Results displayed in tables and graphs
• Automatic cleaning cycle
• Vacuum step-down function to inhibit foaming
• Safety shields and protective doors
• Easy access to components
• Removable receiver
• Data storage in standard formats
• Spreadsheet-compatible data and LIMS export
• Data access through USB drives and Ethernet
• Color printer for hard-copy reports

Standard Components and Accessories:

• Distillation column
• Mounting rack
• 500 mL boiling flask
• Electric heating mantle
• Laboratory jack
• Boiler temperature probe
• Vapor temperature probe
• 200 mL receiver
• Clamps
• Boiling chips
• Heating bath for condenser, side arm, and receiver
• Automatic vacuum system
• PC for distillation control

Dimensions (H × W × D):

• 91.5 × 94 × 53 cm (36 × 37 × 21 inches)

System Weight:

• 91 kg (200 lbs)
