Automatic Viscometry System for Oil and Petroleum Testing Instruments

The Fully Automatic Kinematic Viscometer is designed to measure the kinematic viscosity of Newtonian fluids, including fuels, base oils, formulated oils, petrochemical fluids, lubricants, and diluted polymer solutions. It uses calibrated capillary viscometers based on the Ubbelohde design to measure flow under gravity or vacuum at precisely controlled temperatures. The system covers a wide viscosity range from 0.15 to 25,000 mm²/s and supports sample introduction by vacuum or pressure. It features precise temperature control, accurate flow-time measurement, automatic sample filling, solvent cleaning, drying, and easy viscometer tube replacement. Multiple configurations are available with one or two independently operated baths and one or two viscometer tubes per bath. Each bath includes a 32-position sampling tray for unattended operation. The system offers touchscreen control, storage for up to 10,000 measurement results, and optional PC software for data collection, calculations, and reporting. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum, petrochemical, and diluted polymer viscosity testing applications.

Measuring Range:

• 0.15–25,000 mm²/s at 40°C

Temperature Range:

• 15°C to 150°C (59°F to 302°F)
• An external chiller is required for temperatures around ambient

Temperature Stability:

• 15°C to 100°C: ±0.01°C
• Up to 150°C: ±0.03°C

Timer Accuracy:

• 0.001 seconds

Sample Volume:

• 8–16 mL

Sample Introduction:

• Vacuum or pressure method

Solvent Consumption:

• Single-solvent cleaning: 10–12 mL per cycle
• Dual-solvent cleaning: 12–15 mL per cycle

Available Configurations:

• Single bath with one viscometer tube
• Single bath with two viscometer tubes
• Dual baths with one viscometer tube per bath
• Dual baths with two viscometer tubes per bath
• Each bath operates independently

Sample Throughput:

• Single bath, one tube: Up to 10 measurements per hour
• Single bath, two tubes: Up to 20 measurements per hour
• Dual baths, one tube per bath: Up to 20 measurements per hour
• Dual baths, two tubes per bath: Up to 40 measurements per hour
• Actual throughput depends on sample viscosity, tube selection, temperature, and solvents used

Viscometer System:

• Ubbelohde-based capillary viscometer tubes
• Specially designed tubes covering a 100-fold viscosity range
• Thermal and optical sensors
• Accurate flow-time measurement
• Suitable for petroleum products and diluted polymer solutions

Automatic Sampling and Cleaning:

• 32-position sampling tray per bath
• Supports 16 samples per tube
• Automatic sample filling
• Single- or dual-solvent cleaning
• Automatic cleaning and drying using solvents and air
• Thorough cleaning of all viscometer tube surfaces, including the outside bottom
• Easy tube replacement to minimize downtime
• Optional unattended operation

Temperature Control:

• Precise programmable temperature regulation
• Independent temperature control for each bath
• Optional cooling coil for temperature management

Control and Software:

• Colour touchscreen interface
• Stand-alone touchscreen operation
• Storage for up to 10,000 measurement results
• PC required for full software operation; PC not included
• Advanced PC software for data collection, storage, calculations, and reporting
• Multiple instruments can be controlled using one PC
• Sample queue can be edited without interrupting ongoing tests
• Displays measured flow times, averages, spread, calibration results, viscosity results, and operating status

Communication:

• RS232 interface
• USB data export

Standard Accessories:

• 16-position autosampler per viscometer tube
• 100-fold-range viscometer tube(s)
• Bath oil
• Cooling coil
• Reference standards
• Dual-solvent injection system
• Advanced PC software
