Automatic Viscometry System for Oil Fuel and Petroleum Testing Instruments

The Fully Automatic High-Temperature Kinematic Viscometer is designed to determine the kinematic viscosity of liquid asphalts, road oils, distillation residues, and other highly viscous samples at elevated temperatures. It is suitable for fuels, base oils, formulated oils, vacuum residues, additives, crude oils, waxes, heavy fuel oils, polymers, and asphalts. The programmable system measures viscosities up to 120,000 mm²/s at temperatures up to 150°C. It features automatic sampling, sample preheating, vacuum-based viscometer filling, dual-solvent cleaning, and automatic drying. The Ubbelohde-based viscometer tubes use thermal sensors to measure opaque fluids without requiring reverse-flow tubes. The compact system offers precise temperature control, accurate flow-time measurement, easy tube replacement, and chemically resistant components. It supports touchscreen stand-alone operation, PC-based control, data storage, calculations, and reporting. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for high-temperature petroleum, bitumen, and viscosity testing applications.

Available Models:

• Single-tube model with one viscometer tube in a thermostatic bath
• Dual-tube model with two viscometer tubes in a single bath

Measuring Range:

• Up to 120,000 mm²/s
• Maximum measurement temperature: 150°C

Temperature Range:

• 15°C to 150°C (59°F to 302°F)

Temperature Stability:

• 15°C to 100°C: ±0.01°C
• Up to 150°C: ±0.03°C
• An external chiller is required for temperatures around ambient

Timer Accuracy:

• 0.001 seconds

Sample Volume:

• 12 mL

Sample Introduction:

• Vacuum method

Solvent Consumption:

• 20–30 mL per cycle, depending on the sample

Sample Throughput:

• Single-tube model: Up to 2 measurements per hour
• Dual-tube model: Up to 4 measurements per hour
• Actual throughput depends on viscosity, viscometer tube, temperature, and selected solvents

Viscometer System:

• Ubbelohde-based viscometer tubes
• Thermal sensors for detecting opaque fluids
• Specially designed dual-measurement tubes for unstable samples
• Two measuring sections with approximately similar tube constants
• Dual determination from a single sample introduction

Automatic Sampling and Cleaning:

• Single-position autosampler
• Integrated sample preheating up to 200°C
• Vacuum-based sample filling
• Fully automatic dual-solvent cleaning and drying
• Preheated solvent for efficient viscometer tube cleaning
• Reduced risk of cross-contamination
• Easy viscometer tube replacement

Temperature Control:

• Precise programmable temperature regulation
• Standard viscosity measurement up to 150°C
• Sample preheating up to 200°C

Control and Software:

• Colour touchscreen interface
• Advanced PC software for customizable test methods
• Internal storage for up to 10,000 measurement results
• One PC can control multiple instruments
• Software can collect data from up to four instruments simultaneously
• Multilingual software
• Sample identification and queue management
• Automatic storage of results in an internal database
• Data can also be saved to external drives or network folders

Displayed Measurement Data:

• Average and corrected flow times
• Percentage difference
• Kinematic viscosity result
• Bath temperature and set temperature
• Preheater temperature
• Sample identification
• Test method
• Measuring section
• Previous results
• Operating status, including filling and cleaning

Communication and Data Export:

• RS232 communication
• USB data export
• Wireless data exchange with LIMS
• PC required for full software operation; PC not included

Standard Accessories:

• Single-position autosampler with tube preheater
• Dual-measurement viscometer tube(s)
• Bath oil
• Dual-solvent injection system
• Reference standards
• Advanced PC software
