Automatic Volumetric Karl Fischer Titrator for Oil and Petroleum Testing Equipment

The Automatic Karl Fischer Volumetric Titrator is designed to determine the water content of liquids using the volumetric Karl Fischer titration method. It provides fast and precise water analysis across a wide range of applications.

The instrument uses potentiometric titration in an anhydrous medium. After the sample is added to the reagent, the user enters the sample weight and the titration process begins automatically. Special control algorithms adjust the titration speed according to the reaction rate and continue the process until the endpoint is detected.

The instrument displays the titration curve, measurement drift, and titrant consumption during analysis. Pre-programmed methods support different applications, while a formula generator allows users to customize result calculations and output units.

Manufactured by Atico Export for accurate water content determination and routine quality control in laboratory applications.

• Determination of water content in liquids
• Water analysis in methanol
• Testing of isopropyl alcohol
• Water determination in glycol
• Analysis of other organic liquids
• Quality control of industrial and laboratory liquid samples

Measurement Method :

• Water determination by Karl Fischer volumetry
• Potentiometric titration in an anhydrous medium

Measuring Range :

• 10 ppm to 100%

Display Resolution :

• pH: 0.001
• mV: 0.1

Result Types :

• ppm
• mg/L oil
• Custom units using the formula generator

Suitable Samples :

• Methanol
• Isopropyl alcohol
• Glycol
• Other organic liquids

Dimensions (W × H × D) :

• 11.9 × 17.8 × 11.9 inches (30 × 45 × 30 cm)

Weight of Titrator :

• 3.5 kg (7.8 lbs)

• Complete measuring system for water determination
• Fully automatic volumetric titration
• Karl Fischer volumetric measurement method
• Potentiometric endpoint detection
• Special control algorithms for precise titration parameter adjustment
• Pre-programmed measurement methods for immediate operation
• Real-time display of titration curve and measurement drift
• Display of titration solvent consumption
• Automatic titration until endpoint detection
• Customizable result output using a formula generator
• Multiple result units, including ppm and mg/L
