Automatic Volumetric Titrator for Oil and Petroleum Testing Equipment

The Automatic Volumetric Titrator is designed for the determination of Total Acid Number (TAN), Total Base Number (TBN), hydrogen sulfide, mercaptan sulfur, Bromine Index, and Bromine Number in petroleum products, oils, fats, and hydrocarbons.

The instrument uses potentiometric or volumetric titration methods, depending on the selected application. During TAN and TBN testing, the sample is added to the reagent, and the sample weight is entered into the instrument. Special control algorithms adjust the titration speed according to the reaction rate and continue the process until the endpoint is detected.

For sulfur determination, the instrument uses silver nitrate solution in an anhydrous medium to measure hydrogen sulfide and mercaptan sulfur. Bromine titration measures the bromine consumed by unsaturated constituents in hydrocarbons and oils.

The system features pre-programmed measurement methods, automatic titration control, and a formula generator for customized result calculations.

Manufactured by Atico Export for reliable chemical analysis and quality control in petroleum and industrial laboratories.

• Transformer oils
• Mineral oil products
• Lubricants
• Natural, artificial, and food fats
• Gasoline and kerosene
• Aviation turbine fuels
• Volatile and middle distillates
• Liquefied petroleum gas (LPG)
• Hydrocarbon gases and liquid hydrocarbons
• Petroleum naphtha and low-boiling oils
• Light and heavy cycle oils
• Petroleum distillates and olefin-containing hydrocarbons

Power Supply :

• 100–240 V AC, 50/60 Hz

Measurement Methods :

• Hydrogen sulfide and mercaptan sulfur determination
• Bromine Index and Bromine Number determination

Ordering Information :

Main Instrument :

• Automatic Volumetric Titrator, 100–240 V, 50/60 Hz

• Petroleum distillates
• Kerosene
• Leaded, unleaded, and oxygenated gasoline
• Distillates in the gas oil range
• Commercial propylene trimer and tetramer
• Butene dimer
• Mixed nonenes, octenes, and heptenes
• Olefin-free hydrocarbons or mixtures
