Automotive Electronic Control Device Unit

The Automotive Electronic Control Device Unit included in the allows the flashing an ECU (electronic control unit) with different programs, changing the response of the ECU to different input signals, etc.

ATENG 11402 — Automotive Electronic Control Device Unit

• The “ATENG 11402” unit includes the following circuits:
• Electronic control unit (ECU):
  Communication with sensors and actuators through CAN or LIN network protocols
  or through digital or analog signals.
  Allows self-diagnosis of the ECU to detect faults.
• Allows ECU reprogramming with two engine configurations: naturally aspirated and
  turbocharged.
• Emulated sensor circuits:
  Manifold absolute pressure sensor.
  Accelerator pedal position sensor. ATENG 11402 detail
  Intake air temperature sensor.
  Coolant temperature sensor.
  Exhaust gas recirculation (EGR) temperature sensor.
  Oxygen or Lambda sensor.
  Mass air flow sensor.
  Crankshaft and camshaft position sensors.
  Fuel tank pressure sensor.
• Emulated actuator circuits:
  Canister-purge solenoid valve.
  Turbocharger boost control solenoid.
  Exhaust gas recirculation (EGR) valve.
  Spark plug.
  Fuel injector.
  Electronic throttle valve.
  Engine refrigeration fan.
  Cables and accessories, for normal operation.
