Automotive Fundamental Electrical Circuits Unit

The Automotive Fundamental Electrical Circuits Unit, to study the main electrical circuits found in modern cars, offering a clear and hands-on introduction to contemporary automotive electronics.

ATENG 11395 — Automotive Fundamental Electrical Circuits Unit

• The “ATENG 11395” unit includes the following circuits:
• Power supply circuit:
• 12 VCA power supply.
• 12 VCC power supply.
• Resistive elements circuit:
  Circuit of logarithmic potentiometers, linear potentiometers and fixed resistors with
• the following configurations available: in series, in parallel and mixed.
• Lighting elements circuit:
• Different lamp circuits with the following configurations available: in series and in
  ATENG 11395 detail
  parallel.
  LED diode.
• Relay and stroke end circuit:
• Relay circuit with a 12 VDC coil and three contacts: common, normally open and normally closed.
  End of stroke for relay control.
• Capacitive elements circuit:
  Capacitor with filter function.
  Capacitor with energy storage function.
• Rectifier circuit:
  Half wave and full wave rectifier circuit.
• Temporization circuit:
  Astable multivibrator circuit with 555IC.
  Adjustable voltage divider circuit.
• Logic gates circuit:
• Circuit for mounting the following logic gates: NOT, AND, NAND, OR, NOR, XOR and XNOR.
• Protoboard plate:
  Protoboard plate to assemble experimental circuits without soldering.
  Components to mount a monostable multivibrator or an astable multivibrator circuit with 555IC.
  Cables and accessories, for normal operation.
