Babinet Compensator for Physics Lab Experiments Without Accessories

The Compensator consists of two quartz wedges. One wedge is fixed with its optical axis in one direction, while the other is movable with its optical axis positioned in a perpendicular direction.

Physics Lab Experiments Setup from Atico Exports.

Quartz Wedges :

• Two Quartz Wedges
• One Fixed Wedge
• One Movable Wedge
• Optical Axes Positioned Perpendicular to Each Other

Movable Wedge :

• Operated by a Micrometer Screw

Micrometer Reading Accuracy :

• 0.005 mm

Wedge System :

• Mounted in a Box
• Rotatable on a Circular Scale
• Fine and Coarse Movement Arrangements

Circular Scale Least Count :

• 1/10°

Analyzer :

• Provided with an Independent Scale
• Can Be Adjusted to Any Angular Position with Respect to the Wedges
