Ball Mill Grinder

The Ball Mill Grinder is a bench-top vertical semi-circular planetary ball mill designed for efficient sample grinding and mixing. It features four grinding positions with adjustable variable frequency speed control for precise operation. Equipped with pneumatic spreaders, a cooling fan, and a safety lock door with a see-through window, it ensures safe, reliable, and convenient operation for laboratory applications. Manufactured by Atico Export India.

• Geology laboratories
• Mineral analysis
• Metallurgy
• Electronics industry
• Building material testing
• Ceramic laboratories
• Chemical industry
• Pharmaceutical laboratories
• Cosmetic industry
• Environmental protection
• Research and development laboratories

Capacity :

• 0.2 L

Jar Capacity :

• 10 mL to 50 mL

Timer Range :

• 1 to 9999 Minutes

Forward and Backward Timer Range :

• 1 to 999 Minutes

Speed Revolution :

• 60 to 580 rpm

Speed Rotation :

• 120 to 1160 rpm

Speed Regulation Mode :

• Variable Frequency Speed Control

Feed Size :

• Soil Material ≤10 mm, Other Materials ≤3 mm

Number of Jars :

• 4

Lubrication Mode :

• Grease

Noise Level :

• ≤50 ± 5 dB

Power Consumption :

• 0.09 kW

Power Supply :

• Single Phase, 220 V, 50 Hz

Dimensions (L × W × H) :

• 430 × 250 × 270 mm

Weight :

• 18 kg

• Compact benchtop design
• Smooth, quiet, safe, and reliable operation
• Gear-driven variable speed for stable performance
• Suitable for dry and wet grinding
• Supports mixing of different particle sizes and materials
• Pneumatic spreaders for convenient operation
• Cooling fan for efficient heat dissipation
• Safety cover door with see-through window
• Easy monitoring during operation
