Balmer Series of Hydrogen & Rydberg Constant Optics Educational Kits

The Balmer Series and Rydberg Constant Experiment Apparatus is designed to study the visible emission spectrum of hydrogen and determine the experimental value of the Rydberg constant. The apparatus enables students to investigate the spectral lines produced by electron transitions from higher energy levels to the second energy level of the hydrogen atom. Using a diffraction grating, the collimated light from a Hydrogen-Deuterium lamp is dispersed into its constituent spectral lines. A telescope and digital protractor system are then used to accurately measure diffraction angles, allowing the wavelengths of the Balmer series lines to be calculated. This experiment provides valuable insight into atomic structure, quantum energy levels, spectroscopy, and the relationship between spectral wavelengths and the Rydberg constant. It is an ideal educational tool for university-level physics and optics laboratories. Physics Lab Experiments from Atico Exports.

Experiments and Applications :

Measurement of the Balmer Series :

• Observe the visible hydrogen spectral lines and measure their diffraction angles using the grating and telescope system.

Determination of Spectral Wavelengths :

• Calculate the wavelengths of spectral lines from measured diffraction data.

Determination of the Rydberg Constant :

• Derive the experimental value of the Rydberg constant using measured wavelengths and the Balmer equation.

Study of the Hydrogen Spectrum :

• Analyze electron transitions within the hydrogen atom and understand their relationship to atomic energy levels and spectral emissions.

Hydrogen-Deuterium Lamp :

• Wavelengths: 410, 434, 486, 656 nm

Digital Protractor :

• Resolution: 0.1°

Condensing Lens :

• f = 50 mm

Collimating Lens :

• f = 100 mm

Transmission Grating :

• 600 Lines/mm

Telescope :

• Magnification: 8×
• Objective Lens Diameter: 21 mm
• Internal Reference Line Included

Optical Rail :

• Length: 74 cm
• Aluminum Construction

Optical Rail :

• Quantity: 1

Standard Carriers :

• Quantity: 3

X-Translation Carrier :

• Quantity: 1

Optical Rotation Stage with Digital Protractor :

• Quantity: 1

Telescope :

• Quantity: 1

Lens Holders :

• Quantity: 2

Lenses :

• Quantity: 2

Diffraction Grating :

• Quantity: 1

Adjustable Slit :

• Quantity: 1

Telescope Holder with Tilt Adjustment :

• Quantity: 1

Hydrogen-Deuterium Lamp with Power Supply :

• Quantity: 1 Set

• Stable Aluminum Optical Rail for Easy Alignment
• Hydrogen-Deuterium Light Source Included
• Precise Digital Angle Measurement
• Comprehensive Study of Atomic Spectra
• Detailed Instruction Manual
