Basic Equipment Set for the X-Ray Apparatus Physics School Science STEM Kit

Function and Applications:

• Equipment set for qualitative and quantitative experiments with X-radiation

• Suitable for experiments on:

  • Linear propagation of X-rays
  • Ionization
  • Penetration capability of X-radiation
  • X-ray photography

• Also suitable for demonstrating:

  • Wave nature of X-radiation
  • Fluorescent X-radiation
  • Determination of mass absorption coefficients

• Supplied in a specially moulded storage box

Scope of Delivery:

• Fluorescent screen

• Debye-Scherrer camera

• Film cassettes

• Lead mask

• Plate electrodes on 4 mm contact pin

• Slit diaphragm collimator, 1 mm

• Pin diaphragm collimator, 1 mm diameter

• Ancillary magazine with circular aperture

• Slit diaphragms, 1 mm / 3 mm

• Pin diaphragm, 9.5 mm diameter

• Single crystals:

  • LiF
  • NaCl

• Mini crystals, LiF

• Powder sample, LiF

• Copper wires

• Absorption foils:

  • Ni
  • Cu
  • Co
  • Zn

• Scattering-foil revolver coated with:

  • V
  • Cr
  • Mn
  • Fe
  • Co
  • Ni
  • Cu
  • Zn

• Set of assembly aids:

  • Acetate adhesive
  • Clips

• Specially moulded storage box
