Basic Hydraulic Feed System

The Basic Hydraulic Feed System, is a service unit for different Fluid Mechanics Units as: Basic Fluids Mechanics Integrated Laboratory, "ATENG 11701", Fluid Friction in Pipes Unit, with Basic Hydraulics Feed System "ATENG 11882", etc.

ATENG 12037 — Basic Hydraulic Feed System

Anodized aluminum frame and panels made of painted steel.

The unit includes wheels to facilitate its mobility.

• Centrifugal pump: 0.37 KW, 30 – 80 l/min at 20.1 – 12.8 m, single-phase 200 VAC – 240 VAC/50 Hz or 110 VAC – 127 VAC/60 Hz.
  Stainless steel impeller.
• Tank capacity:140 l approx.
• Flowmeter, range: 600 – 6000 l/h.
  Membrane type flow adjusting valve.
  Safety switch ON/OFF.
  Supports for accommodating the test module.
