With Basic Sequential Circuits Kit, all types of bistables, counters, flip-flops, synchronous sequential circuits and the operation of memories can be studied.
Technical Specifications
ATENG 11315 — Basic Sequential Circuits Kit
SPECIFICATIONS
DC Fixed outputs: + 5 V, ± 12 V, 1 A. Development board.
DC Variable outputs: ± 12 V, 0.5 A. Power supply connector.
AC Outputs: 12 V or 24 V. Digital visual display unit.
Outputs through 2 mm terminals, or connectors Sub-D of Logical source.
25 pins (2 outputs). Set of potentiometers.
Voltage LED indicators. Pulse generator and inverters.
Robust construction. Interrupter.
Power: 110/220 VAC Clock.
Frequency: 50/60 Hz.
DIMENSIONS AND WEIGHTS REQUIRED ELEMENTS (Not included)
Dimensions: 225 x 205 x 100 mm approx. - ATENG 11245. Power Supply.
(8.85 x 8.07 x 3.93 inches approx.) - ATENG 11246. Base Unit, with built-in power supply.
