Basic Set Ultrasonic Doppler Technique Physics School Science STEM Kit

• Kit containing instruments and accessories for general ultrasonic sonography experiments

• Software displays measured data from the ultrasonic Doppler apparatus in real time on a computer screen

• Modular and extendable system for experiments in:

  • Hydraulics
  • Medical diagnostics
    (for training purposes only)

• Designed as a highly didactic introduction to the fundamentals of sonography

• Can be expanded with accessory kits for specialised applications

• Includes experimentation manual

• Ultrasonic pulse Doppler apparatus
• Centrifugal pump
• Ultrasonic gel
• Sonography liquid (1 litre)
• Ultrasonic probe, 2 MHz
• Doppler prism 3/8
• Set of flexible tubes

Ultrasonic Pulse Doppler Apparatus:

• Frequencies:

  • 1 MHz
  • 2 MHz
  • 4 MHz

• Amplification:

  • 10 to 40 dB

• Transmitter power:

  • Low (2 µs burst)
  • High (4 µs burst)

• Sample volume:

  • Small (2 µs receiver gate)
  • Large (full receiver gate, approx. 32 µs)

• Visualisation:

  • LED bar display
  • Adjustable acoustic signal output

• PC connection:

  • USB

• Dimensions:

  • 230 × 236 × 168 mm

• Mains voltage:

  • 90–230 V, 50/60 Hz

• Power consumption:

  • 27 VA
