Basic Unit of Mechanical Drive Systems

The Basic Unit of Mechanical Drive Systems, consists of a main frame where a series of accessories and elements are arranged, distributed in modules of different level, thought to introduce the user in the field of mechanical systems and their components.

ATENG 12302 — Basic Unit of Mechanical Drive Systems

Anodized aluminum frame and panels made of painted steel.

The unit includes wheels to facilitate its mobility.

• Variable speed electric motor:
  1/3 HP.
• 225/120 V.
  Constant speed engine.
  Prony brake.
• Set couplings and shafts:
  Shafts.
  Jaw coupling.
  Sleeve coupling.
  Flange coupling.
  Chain coupling.
  Set pillow block bearings.
• Set of belt drives:
  V belt drive.
  Set of pulleys.
  Sheaves and belt gauges.
  Belt tensioning gauge.
• Set of chain drives: ATENG 12302 detail
  Sprockets.
  Chains.
  Chain connecting link.
  Chain breaker. Elements included
  Chain puller.
• Gear drives set:
  Spur gears.
  Bushings.
• Measurement devices:
  Feeler gauge.
  Dial indicator assembly.
  Photo-reflective tachometer.
  Combination square.
  Level.
  Infrared thermometer.
• Mounting and fixing parts:
  Screws.
  Ball screws.
  Ball nuts.
  Flat washers.
  Corner brackets.
  Shims.
  Risers.
  Jointing material.
• Tool box:
  Straightedge.
  Alignment tools.
  Adjustable wrench.
  Claw extractor.
  Arbor press.
  Inspection mirror.
  Hacksaw.
  Punch.
  Gloves.
  Vernier caliper.
  Others.
• Control panel:
  Metallic box.
  Digital display for frequency.
  Motor speed controller.
  ON/OFF switch for the motor.
  Clutch or brake selector (included in MDSU/3).
  ON/OFF controller for clutch or brake (included in MDSU/3).
  Emergency stop push button.
  Main switch.
  All components to be industrial grade.
  The unit includes a mounting guide and tools.
  Cables and accessories, for normal operation.
