Bench Top Cooling Tower Deluxe

The Bench Top Cooling Tower, for the practical study of evaporative water cooling through the circulation of air and water in an open system.

ATENG 12749 — Bench Top Cooling Tower

Bench-top unit.

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

Diagram in the front panel with distribution of the elements similar to the real one.

Water propeller pump, maximum flow of water of 120 l/h.

• Air propeller with a fan with speed control: 145 m³/h max, 3000 rpm.
• Heating element: 60 °C max.
• Water tank, capacity: 14 l.
  Level switch in the tank.
• Flow meter, range: 0.2 – 2 l/min. ATENG 12749 detail
• Two inclined manometers, length: 300 mm.
  Up to sixteen temperature sensors, “J” type (of dry bulb, wet bulb and water temperature), according to the column supplied.
• It included an optional column type B:
• N° of levels: 8. N° of sheets by level: 10. Total surface: 1.013 m². Height of packaging: 650 mm. Density Area/volume: 58 m²/m³.
• Electronic console:
  Metallic box.
  Temperature sensors connections.
  Digital display for temperature sensors.
  Selector for temperature sensors.
  Heating element controller.
  Pump switch.
  Fan switch and fan controller.
  Cables and accessories, for normal operation.
