Benchtop HTHP Cement Curing Chamber oil and petroleum testing instruments by ATICO EXPORT

The benchtop HTHP cement curing chamber is designed to prepare well cement specimens for compressive strength tests. It is necessary to determine the amount of time required for a cement to develop compressive strength so that drilling and production operations can be resumed as quickly as possible. The goal is to design a slurry that can quickly develop compressive strength so that the “waiting on cement” time may be minimized. The HPHT curing chambers provide a means of curing cement specimens under typical downhole temperatures and pressures.

Maximum temperature :

• 400°F (204°C)

Maximum pressure :

• 5,000 PSI (34.47 MPa)

Weight :

• Approx. 215 lb (94.6 kg)

Dimensions :

• 25” × 16” × 20” (63.5 × 40.6 × 50.8 cm)

Shipping weight :

• 255 lb (115.8 kg)

Shipping dimensions :

• 30” × 20” × 24” (76.2 × 50.8 × 61 cm)

Requirements :

• Power requirements: 220 Volts, 50 / 60 Hz, 40 Amp
• Air supply maximum: 150 PSI (1035 kPa)
• Cooling water supply: 40 PSI (276 kPa)

• Unit may be utilized to test well cements in accordance with API Specification 10
• Electronic timer measures elapsed time and may be programmed to initiate cooling
• Pressure relief valve and safety head with rupture disk provided for safety
• Test cell cures 4 specimens
• Compact design suitable for benchtop operation
• Digital programmable temperature controller
• Coolant system quickly cools the test cell
