BENDING MOMENT IN A BEAM

Each beam is simply supported on vertical supports positionable along the beam lengths. At the 'cut' section, a bearing in one beam rests inside a radiused pocket in the other, restricting vertical movement (removing visible shear force) while permitting free rotation (bending). In their unloaded state, beams are levelled using the supplied level indicator. Learn about BENDING MOMENT IN A BEAM exporters for optimal educational outcomes.. Loads are applied via load hangers and a calibrated weights set. The force transducer output connects to a digital interface (sold separately). Learn about BENDING MOMENT IN A BEAM price for optimal educational outcomes..

• Beam lengths: 650 mm and 350 mm
• Beam cross section: 51 × 38 mm
• Graduations: 50 mm intervals
• Weights set: 1 × 1 N, 2 × 2 N, 2 × 5 N, 2 × 10 N
