Benkelman Beam Device

Benkelman Beam Device, aluminium alloy made, complete with dial indicator and accessories, it is utilized to measure the deflection of the road surface when loaded by the wheels of vehicles.

STANDARDS COMPLIANCE :

• COMPLIED AS PER AASHTO T256-77, CNR N141

Weight (kg) :

• 16

Operation :

• The beam is put in contact with the pavement under test between the tires of the vehicle. The measurement of the deflection is performed when the vehicle passes over the test area.

Specifications :

• Length of the Benkelman beam is 250 cm. Beam fulcrum ratio 4:1.

Supply / Components :

• Supplied complete with wooden carrying case.

Spare Parts & Accessories :

• Wooden Carrying Case
• Analog Dial Gauge, 30 x 0,01 mm
• Digital Dial Gauge, 25 x 0,01 mm
• Digital Dial Gauge, 25 x 0,001 mm
