BIFILAR AND TRIFILAR SUSPENSION

A wall-mounted apparatus supporting wire cables for a two-wire (bifilar) or three-wire (trifilar) suspension system. No drill chucks or cumbersome fixing devices are used, keeping calculations straightforward and changeover between arrangements simple. The bifilar suspension uses an upper plate and two cables at 50 mm radius, with a lower crossbar for attaching test specimens. Learn about BIFILAR AND TRIFILAR SUSPENSION equipment for optimal educational outcomes.. The trifilar suspension uses three equally spaced wires on a pitch circle with a lower plate for specimen attachment. The moment of inertia and radius of gyration of a heavy body are determined by timing oscillations with the supplied stopwatch. Learn about BIFILAR AND TRIFILAR SUSPENSION suppliers for optimal educational outcomes.. Inertia can be adjusted by adding a ring and solid cylinder to the suspended rectangular bar.

• Rectangular bar: 400 (L) × 32 (W) × 32 (H) mm; 3.5 kg
• Solid cylinder: Ø70 mm × 100 mm long; 6.0 kg
• Ring: Ø150 O.D × Ø75 I.D × 25.4 mm thick; 3.7 kg
