Binder Recovery Apparatus

Used for the separation of solvent from the binder/solvent solution and to determine the binder content in an aggregate/bitumen mixture.

Additional Information

The Thermostatically controlled Water Bath may be used also as general purposes water bath.
For more information on the Water Bath, see Water Baths
For more information on the Vacuum Pump, see Vacuum Pumps

STANDARDS COMPLIANCE :

• COMPLIED AS PER BS 598-102, EN 12697-1

Weight (kg) :

• 25

Components :

• The apparatus consists of Thermostatically controlled Water Bath to keep boiling water during all the recovery cycle complete with cover and digital thermostat, Vacuum Pump with Vacuum Gauge Manometer, 6 m Tubing for Vacuum, 1000 ml Filter Flask with rubber bung, Two flat-bottomed glass flasks having 250 ml capacity with rubber bungs and necessary fittings and connections.

Power Supply :

• 220 V, 50-60 Hz, 1 ph

Spare Parts & Accessories :

• Water Bath with Circulation System, 30 lt capacity
• Vacuum Pump, Single Stage, 70 l/min
• Tubing for Vacuum, 6 m
• Vacuum Gauge Manometer, 1000 mbar, 63 mm
• Filter Flask with rubber bung, 1000 ml
• Glass Flask, Flat-bottomed, 250 ml with rubber bungs
