ATENG 10765 — Biomedical Electrosurgery Unit
Bench-top unit.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
- Electrosurgical unit:
- Three monopolar cut modes: pure, blend and enhanced cut.
- Three monopolar coagulation modes: forced, soft and fulguration.
- Four bipolar modes: pure cut, TUR current, bipolar coagulation and vessel sealing.
- RF power pulse emission time: 10 ms – 30 s.
- Electrical input power: 500 VA.
- Selectable input voltage: 90 – 240 VAC.
- Working frequency: 360 kHz.
ATENG 10765 detail
Protective frame.
- Electrosurgical tools:
Needle, blade and ball electrodes (three electrodes of each type).
- Ten electrodes in different shapes:
- 3 mm ball electrode.
- 3 mm ball electrode with angle.
- 4 mm loop electrode.
- 6 mm loop electrode.
Drop electrode.
Noose electrode.
Fine needle electrode.
Hook electrode.
Fine needle with angle electrode.
Needle with angle electrode.
- Electronic console:
Main switch.
Cables and accessories, for normal operation.
